| الاسم التجاري: | Schneider |
| رقم الطراز: | 140DIO33000 |
| الـ MOQ: | 1 |
| السعر: | Negotiations |
| Type | QUANTUM PROCESSOR |
|---|
| Analog I/O modules | Discrete I/O modules | ||
| 140ACI03000 140ACI04000 140ACO02000 140ACO13000 140AII33000 140AII33010 140AIO33000 140AMM09000 140ARI03010 140ATI03000 140AVI03000 140AVO02000 | 140DDI15310 140DDI35300 140DDI35310 140DDI36400 140DDI67300 140DDI84100 140DDI85300 140DAI34000 140DAI35300 140DAI45300 140DAI54000 140DAI54300 | 140DAI55300 140DAI74000 140DAI75300 140DSI35300 140DDO15310 140DDO35300 140DDO35301 140DDO35310 140DDO36400 140DDO84300 140DDO88500 140DAO84000 | 140DAO84210 140DAO84220 140DAO85300 140DRA84000 140DRC83000 140DVO85300 140DDM39000 140DDM69000 140DAM59000 140DII33000 140DIO33000 140DAO84010 |
Unity Processor Modicon Quantum - 548 Kb - 66 Mhz
Quantum | 140DII33000 | Modicon | 140DIO33000 | Processor 400K RAM
Unity processor Modicon Quantum - 548 kB - 66MHz Integrated connection type 1 Modbus Plus 2 Modbus Checks Process control Memory description Internal RAM 548 kB Switch function Slide switch communication port : ASCII/RTU/Memory Slide switch memory port/off Application structure No auxiliary task 64 interrupt tasks 64 I/O interrupt tasks 16 timer interrupt tasks 1 periodic fast task 1 cyclic/periodic master task Execution time per instruction 0.12...0.585 μs on word 0.12...0.585 μs Boolean 0.1...0.27 μs on fixed-point arithmetic 0.1...0.27 μs floating points Execution time for 1 K instruction 2.49 65 % Boolean and 35 % numerical 1.86 100 % Boolean System overhead 1 ms - master task 0.2 ms - fast task Bus current requirement 1800 mA Local signalling 1 LED red for communications error on the Modbus Plus port (ERROR A) 1 LED red for battery needs replacing or is not present (BAT LOW) 1 LED orange for write-protected memory (memory port) 1 LED green for CPU has passed the power-up diagnostic tests (READY) 1 LED green for CPU has been started and is solving logic (RUN) 1 LED green for communications are active on the Modbus port (Modbus) 1 LED green for communications are active on the Modbus Plus port (Modbus Plus) Electrical connection 2 female connectors, connector type: SUB-D 9 for connecting to the Modbus bus 1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus network.
| Manufacturer: | Modicon Quantum |
| Series: | Quantum CPUs |
| Weight: | 2 lb |
| Clock frequency: | 66 MHz |
| Number of slots: | 10 | 16 | 2 | 4 | 6 |
| Number of racks: | 2 - local rack(s) |
| Number of distributed I/O station: | 63 station(s) - 1 rack(s) - 3 distributed network(s) |
| Number of remote I/O station: | 31 - 2 remote rack(s) |
| Discrete I/O number: | 8000 inputs, 8000 outputs - distributed - per network | 31744 inputs, 31744 outputs - remote | Unlimited (27 slots max) - local |
| Analogue I/O number: | 500 inputs, 500 outputs - distributed - per network | 1984 inputs,1984 outputs - remote | Unlimited (27 slots max) - local |
| Application specific I/O: | Accurate time stamping | Counter | High-speed interrupt inputs | Serial link |
| Number of optional modules: | 6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max) |
| Maximum number of connections: | Unlimited (AS-Interface) - local | 4 (AS-Interface) - remote | 2 (Profibus DP) - local | 2 (Modbus) - RS232/485 Modbus/ASCII | 2 (Modbus Plus) - local | 2 (Ethernet TCP/IP) - local | 2 (AS-Interface) - distributed | 1 (USB) |
| Integrated connection type: | 1 Modbus Plus | 2 Modbus |
| Checks: | Process control |
| Memory description: | Internal RAM 548 kB |
| Switch function: | Slide switch communication port : ASCII/RTU/Memory | Slide switch memory port/off |
| Application structure: | No auxiliary task | 64 interrupt tasks | 64 I/O interrupt tasks | 16 timer interrupt tasks | 1 periodic fast task | 1 cyclic/periodic master task |
| Category | 18150 - QUANTUM CONTROLLERS,HSBY,COMM. |
|---|---|
| Discount Schedule | PC21 |
| GTIN | 00785901663386 |
| Nbr. of units in pkg. | 1 |
| Package weight(Lbs) | 1.7 |
| Returnability | Y |
| Country of origin | FR |
| Sustainable offer status | Green Premium product |
|---|---|
| RoHS (date code: YYWW) | Compliant - since 0948 - Schneider Electric declaration of conformity |
| REACh | Reference not containing SVHC above the threshold |
| Product environmental profile | Available |
| Product end of life instructions | Available |
