| الاسم التجاري: | Fluke |
| رقم الطراز: | 721 سلسلة |
| الـ MOQ: | 1 |
| السعر: | Negotistical |
| Instrument Settings | Recall Last Power-On Setup |
| Operating Temperature | -10 °C to +50 °C |
| Storage Temperature (without batteries) | -20 °C to +60 °C |
| Altitude | 2,000 m |
| Protection Rating | IP-40 |
| Power Requirements | 6.0 V DC |
| Battery Life | >35 hours (for primary use) |
| Number of Batteries | 4 Standard AA Batteries |
| Dimensions (H x W x D) | 7.9 x 4.3 x 2.3 in (20 x 11 x 5.8 cm) |
| Weight | 539 g (1 lb 3 oz) |
| Connector/Port Pressure | Two, 1/8 in NPT, 700P Series Pressure Module: RTD Probe |
| Functions | Range | Resolution | Accuracy |
|---|---|---|---|
| mA Measurement | 0 to 24 mA | 0.001 mA | Reading ±0.015% ±0.002mA |
| V DC Measurement | 0 to 30 V DC | 0.001 V | Reading ±0.015% ±0.002 V |
| Temperature Measurement (RTD/Ohms)¹ | -40 °C to 150 °C (-40 °F to 302 °F) | 0.01 °C, 0.01 °F | Reading ±0.015% ±0.02 ohms ±0.1 °C (±0.2 °F) |
| Loop Power Supply | 24 V | N/A | 24 mA @ 24 V |
