| الاسم التجاري: | MITSUBISHI |
| رقم الطراز: | AJ35T-M16B-R |
| الـ MOQ: | 1 |
| السعر: | Negotiations |
The Mitsubishi AJ35T-M16B-R is a 16-point transistor sink output module designed for use with the MELSEC-Q series of Programmable Logic Controllers (PLCs). This module serves as a critical interface, allowing the PLC's CPU to control industrial devices such as solenoid valves, motor starters, relays, and indicator lamps by switching their DC power supply. The "R" suffix indicates that the module's output points are arranged in a common negative (sink) configuration, making it suitable for standard industrial control systems, particularly in regions where this wiring convention is prevalent. It is mounted on a main base unit and connects to field devices via a removable terminal block for easy wiring and maintenance.
The following table outlines the key specifications for the AJ35T-M16B-R module.
| Parameter | Specification |
|---|---|
| Model | AJ35T-M16B-R |
| Product Series | MELSEC-Q Series |
| I/O Type | Output Module |
| Number of Points | 16 points |
| Output Type | Transistor, Sink (Common Negative) |
| Rated Load Voltage | 12-24 VDC |
| Maximum Load Current | 0.5 A / point |
| Maximum In-rush Current | 3 A / point, for 10 ms max |
| ON-State Voltage Drop | 1.5 V max. |
| OFF-State Leakage Current | 0.1 mA max. |
| Response Time | ON: 1 ms max., OFF: 1 ms max. |
| Internal Current Consumption | 5 VDC: 0.12 A (from base unit) |
| Isolation Method | Photocoupler isolation |
| External Connection | 18-point removable terminal block (M3.5 screws) |
| Mounting | MELSEC-Q series main base unit |
| Weight | Approx. 0.2 kg |
| Attribute | Value |
|---|---|
| For Use With | MELSEC Q Series |
| Number of I/O | 2048 |
| Manufacturer Series | MELSEC Q |
| Input Type | Analogue, Digital |
| Voltage Category | 5 V dc |
| Output Type | Analogue, Digital |
| Communication Port Type | RS232C |
| Program Capacity | 32 kB |
| Programming Interface | Computer, Operating Panel |
| Length | 89.3mm |
| Maximum Inputs/Outputs | 8192 |
| Number of Communication Ports | 1 |
| Width | 27.4mm |
| Maximum Operating Temperature | +55°C |
| Dimensions | 89.3 x 27.4 x 98 mm |
| Depth | 98mm |
| Battery Backup | Yes |
| Minimum Operating Temperature | 0°C |
| Mounting Type | DIN Rail |
| Memory | 94 kB |
