| الاسم التجاري: | ABB |
| رقم الطراز: | CI858 3BSE018135R1 |
| الـ MOQ: | 1 |
| السعر: | Negotiations |
| Attribute | Value |
|---|---|
| I/O Current, DC | 500mA |
| 24 V Consumption Typ | 140 MA |
| Temperature, Operating | 0 To +55 °C |
| Temperature, Storage | -25 To +70 °C |
The DriveBus protocol is used to communicate with ABB Drives and ABB Special I/O units. DriveBus is connected to the controller via a CI858 communication interface unit. The DriveBus interface is used for communication between ABB Drives and AC 800M controller.
The DriveBus communication is especially designed for sectional drive applications for ABB rolling mill drive systems, and ABB paper machine control systems. The CI858 is powered by the processor unit, via the CEX-Bus, and therefore does not require any additional external power source.
| Protocol | ABB's DriveBus |
| Article number | 3BSE018135R1 |
| Master or slave | Master |
| Transmission speed | 8 Mbit/s |
| Line redundancy | No |
| Module redundancy | No |
| Hot Swap | Yes |
| Used together with HI Controller | No |
| Max units on CEX bus | 2 |
| Connector | Optical |
| 24 V consumption typ. | typ 200 mA |
| Temperature, Operating | 55 °C |
| Protection class | IP20 according to EN60529, IEC 529 |
| CE- marking | Yes |
| Marine certificates | ABS, BV, DNV-GL, LR, RS, CCS |
| RoHS compliance | EN 50581:2012 |
| WEEE compliance | DIRECTIVE/2012/19/EU |
| Height | 185 mm (7.3 in.) |
| Width | 59 mm (2.3 in.) |
| Depth | 127.5 mm (5.0 in.) |
| Weight (including base) | 700 g (1.5 lbs) |
